Product Description
Applications
Mainly used for compression,packing,compact density,uniform size,convenient transportation,storage and transportation of waste stainless steel,waste aluminum,waste non-ferrous metals and so on.
Features
1.Baling press pressure range is from 200 tons to 500 tons,complete specifications.
2.Hydraulic drive, with upper oil cylinder, no underground foundation.
3.All cylinders are equipped with imported sealing rings with reliable quality and extended service life.
4.Package size,compression chamber size can be customized according to customer requirements
Product Parameters
Model | (ton)
Main Cyl.Force | (mm)
Press Box Size | (mm)
Bale Size | (kg)
Bale Weight | (KW)
Power |
200
|
200
|
2500×1500×1000
|
1500×850
|
800
|
30+30
|
250
|
250
|
2500×1500×1000
|
1500/1800×850
|
950
|
37+37
|
315
|
315
|
2500×1800×1000
|
1500/1800×850
|
1100
|
45+45
|
400
|
400
|
3000×1500/1800×1000
|
1500/1800×850
|
1200-1500
|
55+55
|
500
|
500
|
3000×1500/1800×1000
|
1500/1800×850
|
1300-1800
|
45+45+45
|
